Drifter Rod

Drifter rod is mainly used on the full hydraulic drifting jumbo. This drifting drill rod can be used for roadway excavation blasting and anchor hole drilling in underground mine, as well as used for the excavation of traffic tunnels, hydropower engineering diversion tunnels,underground engineering, etc.

Litian is a well-established drifter rod suppliers, we have two drifter rod factory in China. Our drifter rod has excellent performance in wear resistance, flexibility, and service life, and can fully meet the drilling requirements of various rock hardness.


Drifter Rod Specifications

R32 - R25

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]



R32 R25 Drifter Rod

1870

6' 1 5/8

25

1″

6.9

R32/R25-H25-1870

605-5919-202

Drifter rod, Hex 25, R32 - R25

2175

7' 1 5/8

25

1″

8.4

R32/R25-H25-2175

605-5922-202



2475

8' 1 1/2

25

1″

9.5

R32/R25-H25-2475

605-5925-202



2630

8' 7 1/2

25

1″

10

R32/R25-H25-2630

605-5926-202



2785

9' 1 5/8

25

1″

11

R32/R25-H25-2785

605-5928-202



2935

9' 7 1/2

25

1″

16

R32/R25-H25-2935

605-5929-202



3090

10' 1 5/8

25

1″

12

R32/R25-H25-3090

605-5931-202



3340

10' 11 1/2

25

1″

12

R32/R25-H25-3340

605-5933-202



3700

12' 1 5/8

25

1″

14

R32/R25-H25-3700

605-5937-202









R32 R25 Drifter Drill Rod

2630

8' 7 1/2

28

1/8

14

R32/R25-H28-2630

605-8326-202

Drifter rod, Hex 28, R32 - R25

3090

10' 1 5/8

28

1 1/8

16

R32/R25-H28-3090

605-8331-202


R32 - R28

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]





2475

8' 1 1/2

28

1/8

12

R32/R28-H28-2475

605-6225-202



2785

9' 1 5/8

28

1/8

14

R32/R28-H28-2785

605-6228-202

R32 R28 Drifter Rod

3090

10' 1 5/8″

28

1/8

15

R32/R28-H28-3090

605-6231-202

Drifter rod, Hex 28, R32 - R28

3340

10' 11 1/2

28

1/8

16

R32/R28-H28-3340

605-6233-202



3700

12' 1 5/8

28

1/8

20

R32/R28-H28-3700

605-6237-202



4305

14' 1 1/2

28

1 1/8

21

R32/R28-H28-4305

605-6243-202


R32 - SR28

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]





2100

6' 10 5/8

28

1/8

10

R32/SR28-H28-2100

605-10521-202



2300

7' 6 1/2

28

1/8

11

R32/SR28-H28-2300

605-10523-202

R32-SR28-H28.jpg2400

7' 10 1/2″

28

1/8

12

R32/SR28-H28-2400

605-10524-202

Drifter rod, Hex 28, R32 - SR28

2600

8' 6 3/8

28

1/8

12.5

R32/SR28-H28-2600

605-10526-202



2800

9' 2 1/4

28

1/8

14

R32/SR28-H28-2800

605-10528-202



2950

9' 8 1/8

28

1 1/8

15

R32/SR28-H28-2950

605-10529-202


309010' 1 5/8281/815.8R32/SR28-H28-3090605-10531-202

330010' 9 7/8281/817R32/SR28-H28-3300605-10533-202

370012' 1 5/8281/819R32/SR28-H28-3700605-10537-202

553018' 1 3/4281/828.8R32/SR28-H28-5530605-10555-202


R38 - R32

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]



R38 R22 Drifter Rod

2475

8' 1 1/2

32

1 1/4

16

R38/R32-H32-2475

607-6625-202

Drifter rod, Hex 32, R38 - R32


3090

10' 1 5/8

32

1/4

20

R38/R32-H32-3090

607-6631-202



3700

12' 1 5/8

32

1/4

24

R38/R32-H32-3700

607-6637-202



4305

14' 1 1/2

32

1/4

27

R38/R32-H32-4305

607-6643-202



4915

16' 1 1/2

32

1/4

31

R38/R32-H32-4915

607-6649-202









R32 R25 Drifter Drill Rod

3090

10' 1 5/8

35

1 3/8

24

R38/R32-H35-3090

607-8431-202

Drifter rod, Hex 35, R38 - R32


3700

12' 1 5/8

35

3/8

28

R38/R32-H35-3700

607-8437-202



4305

14' 1 1/2

35

3/8

34

R38/R32-H35-4305

607-8443-202



4915

16' 1 1/2

35

3/8

37

R38/R32-H35-4915

607-8449-202



5525

18' 1 1/2

35

3/8

42

R38/R32-H35-5525

607-8455-202


T35 - R35

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]




4305

14' 1 1/2

39

1 1/2

35

MF-T35/R35-D39-4305

621-7543-202

MF Drifter rod, Round 35, T35 - R35

4915

16' 1 1/2

39

1/2

40

MF-T35/R35-D39-4915

621-7549-202



5525

18' 1 1/2

39

1/2

45

MF-T35/R35-D39-5525

621-7555-202



6135

20' 1 1/2

39

1/2

50

MF-T35/R35-D39-6135

621-7561-202


T38 - R32

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]



T38 R32 Drifter Rod

3090

10' 1 5/8

32

1 1/4

24

T38/R32-H32-3090

622-6531-202

Drifter rod, Hex 32, T38 - R32

3700

12' 1 5/8

32

1/4

26

T38/R32-H32-3700

622-6537-202



4305

14' 1 1/2

32

1/4

28

T38/R32-H32-4305

622-6543-202









T38 R32 Drifter Drill Rod

2475

8' 1 1/2

35

1 3/8

19

T38/R32-H35-2475

622-8525-202

Drifter rod, Hex 35, T38 - R32

3090

10' 1 5/8

35

3/8

24

T38/R32-H35-3090

622-8531-202



3700

12' 1 5/8

35

3/8

28

T38/R32-H35-3700

622-8537-202



4305

14' 1 1/2

35

3/8

32

T38/R32-H35-4305

622-8543-202



4915

16' 1 1/2

35

3/8

37

T38/R32-H35-4915

622-8549-202



5525

18' 1 1/2

35

3/8

42

T38/R32-H35-5525

622-8555-202



6440

21' 1 1/2

35

3/8

46

T38/R32-H35-6440

622-8564-202









T38R32 MF Drifter Rod370012' 1 5/8353/829MF-T38/R32-H35-3700622-7237-202
MF Drifter rod, Hex 35, T38 - R32430514' 1 1/2353/834MF-T38/R32-H35-4305622-7243-202









T38 - R35

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]



T38 R35 Drifter Rod

4305

14' 1 1/2

35

1 3/8

34

T38/R35-H35-4305

622-8643-202

Drifter rod, Hex 35, T38 - R35

4915

16' 1 1/2

35

3/8

37

T38/R35-H35-4915

622-8649-202



5525

18' 1 1/2

35

3/8

42

T38/R35-H35-5525

622-8655-202



6135

20' 1 1/2

35

3/8

46

T38/R35-H35-6135

622-8661-202










T38 R35 Drifter Drill Rod


4305

14' 1 1/2

39

1 1/2

35

T38/R35-D39-4305

622-5243-202

Drifter rod, Round 39, T38 - R35

4915

16' 1 1/2

39

1 1/2

40

T38/R35-D39-4915

622-5249-202



5525

18' 1 1/2

39

1 1/2

45

T38/R35-D39-5525

622-5255-202



6135

20' 1 1/2

39

1 1/2

49

T38/R35-D39-6135

622-5261-202


T38 - SR35

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]




2670

8' 9 1/8

35

1 3/8

21

T38/SR35-H35-2670

622-10627-202

Drifter rod, Hex 35, T38 - SR35

3150

10' 4″

35

3/8

24.5

T38/SR35-H35-3150

622-10631-202



3700

12' 1 5/8

35

3/8

28.8

T38/SR35-H35-3700

622-10637-202


431014' 1 5/8353/833.7T38/SR35-H35-4310622-10643-202



4920

16' 1 3/4

35

3/8

38.4

T38/SR35-H35-4920

622-10649-202











4310

14' 1 5/8

39

1 1/2

34

T38/SR35-D39-4310

622-10743-202

Drifter rod, Round 39, T38 - SR35

4920

16' 1 3/4

39

1 1/2

39

T38/SR35-D39-4920

622-10749-202



5530

18' 1 3/4

39

1 1/2

43

T38/SR35-D39-5530

622-10755-202



6100

20'  1/8

39

1 1/2

48

T38/SR35-D39-6100

622-10761-202


640021'391/251T38/SR35-D39-6400622-10764-202


T38 - SR38

Length

Diameter

Weight

Model No.

Part No.


[mm]

[ft-in]

[mm]

[in]

[kg]




4920

16' 1 3/4

38

1 1/2

41.8

T38/SR38-H38-4920

622-10849-202

Drifter rod, Hex 38, T38 - SR38

5500

18'  1/2

38

1/2

46

T38/SR38-H38-5500

622-10855-202



6100

20'

38

1/2

51

T38/SR38-H38-6100

622-10861-202



Can't find the drill rod you want? Please contact us! ↓


Drifting Drill Rod Features

Drifter rod is a kind of threaded drill rod used in conjunction with a hydraulic trolley, and is widely used in face drilling and bolting in underground mining and tunnel excavation operations.


The main thread types of drifter rods are R25, R28, R32, R35, T38, which can be divided into extension rods and speed rods, hexagonal rods and round rods. Among them, hexagonal extension rods are mostly used. As a reliable drifter rod factory and drifter rod suppliers, Litian is committed to supplying a variety of standard lengths of drifting drill rod (ranging from 600mm to 6440mm in length) to match most face drilling rigs.


We use specific high-quality steels to maximize the wear resistance, fatigue resistance and corrosion resistance of drifter rod. In production processing, through advanced machining technology, our drilling tools have higher rock penetration, which can greatly reduce the deflection to improve the straightness of the drilling hole, and ultimately  reduce the overall production cost.


Whether in the selection of steel materials or in the optimization of processing technology, we have been exploring, developing and optimizing rock drilling tools all the time in combination with the feedback of field tests.


Drifter Rod for Drifting Bolting Tunneling Download
